Heavy-Duty Waterproof Formwork Plywood for Construction Excellence
GET QUOTE
Piccaso Shuttering Plywood is specifically engineered for concrete formwork applications with exceptional strength and water resistance. Designed to withstand multiple concrete pours and harsh construction environments, our shuttering plywood ensures smooth concrete finishes and reduced material waste on your project sites.
Each sheet is manufactured using advanced hot-press technology with marine-grade adhesives that provide superior bonding strength and enhanced moisture resistance, making it the ideal choice for demanding construction applications.
Manufactured with BWP (Boiling Water Proof) grade phenolic resins that provide exceptional resistance to moisture, rain, and harsh weather conditions at construction sites.
Engineered to withstand 8-10 concrete pours without significant degradation, ensuring cost-effectiveness through multiple reuse cycles in construction projects.
Specially treated face veneers that provide smooth concrete surfaces with minimal surface defects, reducing the need for extensive post-pour finishing work.
Exceptional load-bearing capacity that withstands the substantial pressure of wet concrete without deformation, ensuring precise structural dimensions.
Available with phenolic film overlay for enhanced durability, smoother concrete finish, and even greater reusability in demanding construction environments.
Optimized reusability and durability significantly reduce formwork costs over the project lifecycle, providing excellent return on investment for contractors.
Piccaso Shuttering Plywood is engineered for a wide range of concrete formwork applications:
Piccaso Shuttering Plywood exceeds industry standards for construction-grade formwork panels.
| SPECIFICATION | DESCRIPTION |
|---|---|
| Grade | BWP (Boiling Water Proof) |
| Standard | IS:4990 |
| Core Type | Phenolic Resin (Exterior Grade) |
| Core Material | Selected Hardwood/Tropical Hardwood |
| Face Veneer | Gurjan/Hardwood (Available with Phenolic Film Coating) |
| Moisture Content | 5-8% |
| Density | 750-800 kg/m³ |
| Glue Bond Strength | Superior Water & Weather Resistance |
| Modulus of Elasticity | 6000-7000 N/mm² |
| Bending Strength | 50-60 N/mm² |
| Available Sizes | 8' x 4' (2440mm x 1220mm) and 7' x 3' (2135mm x 915mm) |
| Available Thicknesses | 12mm, 18mm, 19mm, 21mm |
| Reusability | 8-10 Concrete Pours (Standard), 15+ (Film Faced) |
| Warranty | 3 Years (Against Manufacturing Defects) |
Elevate your construction projects with premium shuttering plywood that delivers exceptional durability, reusability, and concrete finish quality while reducing your formwork costs.
